Thermaltake

Thermaltake Core P8 Tempered Glass Full Tower Chassis

Regular price ₹ 18,800.00
Regular price Sale price ₹ 18,800.00
Sale Sold out
Tax included. Shipping calculated at checkout.

The Core P8 TG is a transformable E-ATX Full Tower Chassis that can be either used as a closed or open styled case with Tt LCS Certification.

P/N CA-1Q2-00M1WN-00
SERIES Core
MODEL Core P8 TG
CASE TYPE Full Tower
DIMENSION (H X W X D) 660 x 260 x 626 mm
(26 x 10.24 x 24.65 inch)
NET WEIGHT 22.6 kg / 49.8 lbs
SIDE PANEL Tempered Glass x 3 (4mm thickness)
COLOR Black
MATERIAL SPCC
DRIVE BAYS
-ACCESSIBLE
-HIDDEN

1 x 2.5’’ (with Pump Bracket)
3 x 3.5’’ or 6 x 2.5’’ (With HDD Bracket)
EXPANSION SLOTS 8
MOTHERBOARDS 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX),
12” x 9.6” (ATX), 12” x 13”(E-ATX)
I/O PORT 1 x USB 3.1 (Gen 2) Type C, 2 x USB 3.0, x 2 USB 2.0, 1 x HD Audio
PSU Standard PS2 PSU (optional)
FAN SUPPORT Front: 4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm
3 x 140mm or 2 x 140mm or 1 x 140mm
Top: 4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm
3 x 140mm or 2 x 140mm or 1 x 140mm
Rear: 1 x 120mm or 2 x 120mm ,
Right: 4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm
3 x 140mm or 2 x 140mm or 1 x 140mm
Bottom: 4 x 120mm or 3 x 120mm or 2 x 120mm or 1 x 120mm
3 x 140mm or 2 x 140mm or 1 x 140mm
RADIATOR SUPPORT Front: 1 x 480mm or 1 x 360mm or 1 x 240mm or 1 x 120mm
1 x 420mm or 1 x 280mm or 1 x 140mm
Top: 1 x 360mm or 1 x 240mm or 1 x 120mm
1 x 280mm or 1 x 140mm
Right: 1 x 480mm or 1 x 360mm or 1 x 240mm or 1 x 120mm
1 x 420mm or 1 x 280mm or 1 x 140mm
Bottom: 1 x 240mm or 1 x 120mm (With P5 DP-D5 ) ,
CLEARANCE CPU cooler height limitation: 180mm
VGA length limitation: 280mm (With Reservoir)
320mm (Without Reservoir)
PSU length limitation: 200mm
