- NVIDIA TURING™: ROG GeForce RTX™ graphics cards are powered by the Turing™ GPU architecture and the all-new RTX platform. This gives you up to 6X the performance of previous-generation graphics cards and brings the power of real-time ray tracing and AI to games.
- DirectX 12: Power new visual effects and rendering techniques for more lifelike gaming.
- NVIDIA Shadowplay™ Record and share high-quality gameplay videos, screenshots, and livestreams with your friends.
- Patented Wing-blade Fans deliver high air pressure, reduced noise levels, IP5X certified dust resistance, and 0dB mode for silent gaming.*
- MaxContact Technology allows 2X more contact with the GPU chip for improved thermal transfer.
- Auto-Extreme Technology uses automation to enhance reliability.
- Super Alloy Power II includes premium alloy chokes, solid polymer capacitors, and an array of high-current power stages to fuel Turing™’s cores.
- ASUS FanConnect II equips 2 hybrid-controlled fan headers for optimal system cooling.
- GPU Tweak II provides intuitive performance tweaking and thermal controls.
Graphics Engine | NVIDIA® GeForce RTX™ 2060 |
Bus Standard | PCI Express 3.0 |
OpenGL | OpenGL®4.5 |
Video Memory | GDDR6 6GB |
Engine Clock |
OC Mode - GPU Boost Clock : 1860 MHz , GPU Base Clock : 1395 MHz Gaming Mode (Default) - GPU Boost Clock : 1830 MHz , GPU Base Clock : 1365 MHz |
CUDA Core | 1920 |
Memory Interface | 192-bit |
Resolution | Digital Max Resolution:7680x4320 |
Interface |
HDMI Output : Yes x 2 (Native) (HDMI 2.0b) Display Port : Yes x 2 (Native) (DisplayPort 1.4) HDCP Support : Yes (2.2) |
Maximum Display Support | 4 |
NVlink/ Crossfire Support | No |
Recommended PSU | 500W |
Power Connectors | 1 x 6-pin, 1 x 8-pin |
Accessories |
1 x ROG Velcro Hook & Loop 1 x CD 1 x Quick Guide |
Software | ASUS GPU Tweak II & Driver |
Dimensions |
11.81 " x 5.2 " x 1.97 " Inch 30 x 13.2 x5 Centimeter |
