Intel NUC i5 11th Generation NUC11PAHi50Z Barebone Kit

• Supported Operating Systems : Windows 11, 64-bit*, Windows 10, 64-bit*

• Board Number : NUC11PABi5

• Board Form FactorUCFF (4" x 4")

• SocketSoldered-down BGA

• Internal Drive Form Factor : M.2 and 2.5" Drive

• # of Internal Drives Supported : 2

• Lithography : 14 nm

• TDP : 25 W

• DC Input Voltage Supported : 19 VDC

• Processor Included Intel® Core™ i5-10210U Processor (6M Cache, up to 4.20 GHz)

• Intel vPro® Platform Eligibility ^‡No

• Total Cores : 4

• Total Threads : 8

• Processor Base Frequency : 1.60 GHz

• Max Turbo Frequency : 4.20 GHz

• Warranty Period : 3 yrs

Memory & Storage

• Max Memory Size (dependent on memory type )64 GB

• Memory Types :
  DDR4-3200 1.2V SO-DIMM
  Max # of Memory Channels 2

• Max Memory Bandwidth 42.6 GB/s

• Max # of DIMMs 2

• ECC Memory Supported ^‡No


Processor Graphics

• Integrated Graphics Yes

• Graphics Output HDMI 2.0b; USB-C (DP1.4); MiniDP 1.4

• # of Displays Supported 3


Expansion Options

• PCI Express RevisionGen3

• PCI Express Configurations ^‡M.2 slot with PCIe X4 lanes

• Removable Memory Card SlotSDXC with UHS-II support

• M.2 Card Slot (storage)22x80


I/O Specifications

USB Configuration 2x front (Type-A, Type-C) and 3x rear USB 3.2 Gen2 (2x Type-A, Type-C); USB 2.0, USB 3.1 Gen2 via internal headers

USB Revision  2.0, 3.2 Gen2

USB 2.0 Configuration (External + Internal) 0 + 1

USB 3.0 Configuration (External + Internal) 2B 2F + 1

Total # of SATA Ports 2

Max # of SATA 6.0 Gb/s Ports 2

Audio (back channel + front channel) 7.1 digital (HDMI mDP); L+R out, mono mic in (F)

Integrated LAN Intel® Ethernet Controller i225-V

Wireless Included Intel® Wi-Fi 6 AX201 (Gig+)

Bluetooth Version 5.2

Consumer Infrared Rx Sensor  Yes

Additional Headers CEC, USB3.1, USB2.0, FRONT_PANEL, RGB

• of Thunderbolt™ Ports 1x Thunderbolt™ 3

Package Specifications

• Chassis Dimensions 117 x 112 x 51mm


Advanced Technologies

• Intel® Optane™ Memory Supported ^‡Yes

• Intel® Virtualization Technology for Directed I/O (VT-d) ^‡Yes

• Intel vPro® Platform Eligibility ^‡No

• TPMNo

• Intel® HD Audio TechnologyYes

• Intel® Rapid Storage TechnologyYes

• Intel® Virtualization Technology (VT-x) ^‡Yes

• Intel® Platform Trust Technology (Intel® PTT)Yes


Security & Reliability

• Intel® AES New InstructionsYes
