About this product
Essentials
Product Collection
Intel® NUC Kit with 10th Generation Intel® Core™ Processors
Supported Operating Systems
Windows 11, 64-bit*, Windows 10, 64-bit*
Board Number
NUC10i3FNB
Board Form Factor
UCFF (4" x 4")
Socket
Soldered-down BGA
Internal Drive Form Factor
M.2 and 2.5" Drive
# of Internal Drives Supported
2
TDP : 25 W
DC Input Voltage Supported
19 VDC
Recommended Customer Price : $322.66 - $325.12
Processor Included : Intel® Core™ i3-10110U Processor (4M Cache, up to 4.10 GHz)
Intel vPro® Platform Eligibility ‡ : No
Total Cores : 2
Total Threads : 4
Processor Base Frequency : 2.10 GHz
Lithography : 14 nm
Max Turbo Frequency : 4.10 GHz
Warranty Period : 3 yrs
Supplemental Information
Embedded Options Available : No
Description : Other features: Includes far-field quad array microphones
Memory & Storage
Max Memory Size (dependent on memory type) : 64 GB
Memory Types : DDR4-2666 1.2V SO-DIMM
Max # of Memory Channels : 2
Max Memory Bandwidth : 42.6 GB/s
Max # of DIMMs : 2
ECC Memory Supported ‡ : No
Processor Graphics
Integrated Graphics ‡ : Yes
Graphics Output : HDMI 2.0b; USB-C (DP1.2)
# of Displays Supported ‡ : 3
Expansion Options
PCI Express Revision : Gen3
PCI Express Configurations ‡ : M.2 slot with PCIe X4 lanes
Removable Memory Card Slot : SDXC with UHS-II support
M.2 Card Slot (storage) : 22x42/80
I/O Specifications
# of USB Ports : 7
USB Configuration: 2x front (Type-A, Type-C) and 3x rear USB 3.1 Gen2 (2x Type-A, Type-C); 2x USB 2.0 via internal headers
USB Revision : 2.0, 3.1 Gen2
USB 2.0 Configuration (External + Internal): 0 + 2
USB 3.0 Configuration (External + Internal) : 2B 2F + 0
Total # of SATA Ports : 2
Max # of SATA 6.0 Gb/s Ports: 2
RAID Configuration : 2.5" HDD/SSD + M.2 SATA SSD (RAID-0 RAID-1)
Audio (back channel + front channel): 7.1 digital (HDMI mDP); L+R mic (F)
Integrated LAN : Intel® Ethernet Connection I219-V
Integrated Wireless‡ : Intel® Wi-Fi 6 AX201
Integrated Bluetooth : Yes
Consumer Infrared Rx Sensor : Yes
Additional Headers : CEC, 2x USB2.0, FRONT_PANEL, RGB
# of Thunderbolt™ Ports : 1x Thunderbolt™ 3
Package Specifications
Chassis Dimensions
117 x 112 x 51mm
Advanced Technologies
Intel® Optane™ Memory Supported ‡
Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
Yes
Intel vPro® Platform Eligibility ‡
No
TPM
No
Intel® HD Audio Technology
Yes
Intel® Rapid Storage Technology
Yes
Intel® Virtualization Technology (VT-x) ‡
Yes
Intel® Platform Trust Technology (Intel® PTT)
Yes
Security & Reliability
Intel® AES New Instructions
Yes
