About this product
Designed from the ground up, the Define R6 goes beyond iteration with a profound stride of innovation – a sizeable step forward from preceding models of the world-renowned Define Series.
- • Built for silence with industrial dampening on side, top and front panels
- • Reversible front door with anodized aluminum cover and dual mounting system
- • Nine fan positions with intuitive layout and clear airflow paths for massive cooling
Warranty : 2 Years
Specifications
-
3.5"/2.5" Universal drive brackets : 6
-
Dedicated 2.5" drive brackets : 2
-
Dedicated 5.25" drive bracket : 1 (removable)
-
Expansion slots : 7 + 2 vertical
-
Front ports : 2x USB 3.0, 2x USB 2.0
-
Total fan mounts : 9
-
Front fan : 3x 120 mm or 2x 140 mm (2x Dynamic X2 GP-14 included)
-
Top fan : Standard layout: 3x 120 mm or 2x 140 mm; Open layout: 3x 120/140 mm
-
Rear fan : 1x 120/140 mm (1x Dynamic X2 GP-14 included)
-
Bottom fan : 2x 120/140 mm
-
Dust filters : Bottom fan + PSU, Front fans, Top panel
-
Cable routing grommets : Yes
-
Fixed velcro straps : Yes
-
Tool-less push-to-lock : Both side panels
-
Captive thumbscrews : HDD brackets, SSD brackets
-
Left side panel : Industrial sound-dampened steel
-
Right side panel : Industrial sound-dampened steel
Compatibility
-
Power supply type : ATX
-
Motherboard compatibility : eATX (up to 285 mm wide), ATX, mATX, ITX
-
Front radiator : 120/240/360 mm, 140/280 mm
-
Top radiator : Standard layout: 120/240/360 mm (max 35 mm motherboard component height); Open layout: 120/240/360 mm, 140/280/420 mm (max 35 mm motherboard component height)
-
Rear radiator : 120 mm
-
Bottom radiator : 120/240 mm, 140/280 mm
-
PSU max length : 300 mm
-
GPU max length : 440 mm (with front fan mounted); Standard layout: Maximum width 155 mm (including power connectors) for graphics cards longer than 300 mm
-
CPU cooler max height : 185 mm
-
Cable routing space : 23 mm
-
Vertical GPU Support (with Flex VRC-25) : 31mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling
Dimensions
-
Case dimensions (LxWxH) : 543 x 233 x 465 mm
-
Case dimensions w/o feet/protrusions/screws : 535 x 233 x 448 mm
-
Net weight : 12.4 kg
-
Package dimensions (LxWxH) : 560 x 347 x 650mm
-
Package weight : 14.4 kg
-
Volume : 55.9 liters
