ASUS ZenWiFi AX Mini (XD4) Routers
ASUS ZenWiFi AX Mini (XD4) Routers
Regular price
₹ 21,637.00
Regular price
Sale price
₹ 21,637.00
Unit price
per
Tax included.
Couldn't load pickup availability
Description
Description
Model Name
XD4 (B-1-PK)
XD4 (W-1-PK)
XD4 (B-3-PK)
XD4 (B-2-PK)
XD4 (W-2-PK)
XD4 (W-3-PK)
XD4 (W-1-PK)
XD4 (B-3-PK)
XD4 (B-2-PK)
XD4 (W-2-PK)
XD4 (W-3-PK)
Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6
Product Segment
AX1800 ultimate AX performance : 1201 Mbps+ 574 Mbps
AX technology
Yes
Data Rate
802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 4 (802.11n) : up to 300 Mbps
WiFi 5 (802.11ac) : up to 867 Mbps
WiFi 5 (802.11ac) (1024QAM) : up to 4808 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 433 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 4 (802.11n) : up to 300 Mbps
WiFi 5 (802.11ac) : up to 867 Mbps
WiFi 5 (802.11ac) (1024QAM) : up to 4808 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 433 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps
Antenna
Internal dual-band antenna x 2
Transmit/Receive
MIMO technology
2.4GHz 2x2
5GHz 2x2
2.4GHz 2x2
5GHz 2x2
Memory
256 MB Flash, 256 MB RAM
Boosts speed
MIMO technology
Operating Frequency
2.4 G Hz / 5 GHz
Ports
RJ45 for Gigabits BaseT for WAN/LAN x 1, RJ45 for Gigabits BaseT for LAN x1
Button
WPS Button, Reset Button
LED Indicator
Power x 1
Power Supply
"AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 1.5 A current"
DC Output : 12 V with max. 1.5 A current"
Package content
‧Router (XD4R)
‧RJ45 Ethernet cable
‧Power adapter
‧Quick start guide
‧Warranty Card
‧Router (XD4R)
‧Node (XD4N)
‧RJ45 Ethernet cable
‧Power adapter
‧Quick start guide
‧Warranty Card
‧RJ45 Ethernet cable
‧Power adapter
‧Quick start guide
‧Warranty Card
‧Router (XD4R)
‧Node (XD4N)
‧RJ45 Ethernet cable
‧Power adapter
‧Quick start guide
‧Warranty Card
Product Weight (g)
295 g
Remark
3-pack router*1+node*2
2-pack router*1+node*1
1-pack router*1
Content may vary in different regions and packages.
2-pack router*1+node*1
1-pack router*1
Content may vary in different regions and packages.
AiMesh
AiMesh : Yes
Primary AiMesh router : Yes
AiMesh node : Yes
Primary AiMesh router : Yes
AiMesh node : Yes
Router APP
ASUS Router APP : Yes
Game
Game Boost/acceleration : No
WTFast : No
WTFast : No
Alexa
Support Alexa skill : Yes
IFTTT
Support IFTTT : Yes
AiProtection
AiProtection : AiProtection Classic
Router Security Assessment : No
Malicious site blocking : Yes
Two-Way IPS : No
Infected Device Prevention and Blocking : Yes
Router Security Assessment : No
Malicious site blocking : Yes
Two-Way IPS : No
Infected Device Prevention and Blocking : Yes
Parental Control
Parental Control : Yes
Parental Control Customized Internet schedule : Yes
Parental Control Customized Internet schedule : Yes
Traffic Control
Adaptive QoS : No
Bandwidth Monitor : Yes
Bandwidth limiter : Yes
Traditional QoS : Yes
Maximum Traditional QoS rule : 32
Traffic Monitor : No
Real-time traffic monitor : Yes
Wired Traffic Monitor : Yes
Wireless Traffic Monitor : Yes
Traffic Analyzer : No
Website history : No
Bandwidth Monitor : Yes
Bandwidth limiter : Yes
Traditional QoS : Yes
Maximum Traditional QoS rule : 32
Traffic Monitor : No
Real-time traffic monitor : Yes
Wired Traffic Monitor : Yes
Wireless Traffic Monitor : Yes
Traffic Analyzer : No
Website history : No
Wireless
IPv6 : Yes
MU-MIMO : Yes
Wi-Fi Encryption : WPA3-Personal, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS support
UTF-8 SSID : Yes
Guest Network : Yes
Maximum Guest Network rule : 9
Guest Network Connection time limit : Yes
WPS : Yes
Wi-Fi MAC address filter : No
Wireless scheduler : No
Airtime fairness : No
RADIUS Server : No
Universal beamforming : No
Explicit beamforming : No
MU-MIMO : Yes
Wi-Fi Encryption : WPA3-Personal, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS support
UTF-8 SSID : Yes
Guest Network : Yes
Maximum Guest Network rule : 9
Guest Network Connection time limit : Yes
WPS : Yes
Wi-Fi MAC address filter : No
Wireless scheduler : No
Airtime fairness : No
RADIUS Server : No
Universal beamforming : No
Explicit beamforming : No
WAN
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Dual WAN : No
WAN Aggregation : No
3G/4G LTE dongle : No
Android tethering : Yes
Port forwarding : Yes
Port triggering : Yes
DMZ : Yes
DDNS : Yes
NAT Passthrough : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
Let's Encrypt : Yes
Dual WAN : No
WAN Aggregation : No
3G/4G LTE dongle : No
Android tethering : Yes
Port forwarding : Yes
Port triggering : Yes
DMZ : Yes
DDNS : Yes
NAT Passthrough : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
Let's Encrypt : Yes
LAN
DHCP Server : Yes
IGMP snooping : Yes
IPTV : Yes
LAN Link Aggregation : No
Manually assign IP address : Yes
Maximum manually assign IP address rule : 64
IGMP snooping : Yes
IPTV : Yes
LAN Link Aggregation : No
Manually assign IP address : Yes
Maximum manually assign IP address rule : 64
VPN
VPN Client L2PT : Yes
VPN Client OVPN : Yes
VPN Client PPTP : Yes
VPN Server IPSec : Yes
VPN Server OVPN : Yes
VPN Server PPTP : Yes
VPN Fusion : No
VPN Client OVPN : Yes
VPN Client PPTP : Yes
VPN Server IPSec : Yes
VPN Server OVPN : Yes
VPN Server PPTP : Yes
VPN Fusion : No
USB application
HDD hibernation : No
Safely Remove disk : No
AiCloud : No
Download master : No
AiDisk : No
Media Server : No
Time Machine : No
Samba Server : No
FTP Server : No
Shared Folder privileges : No
Safely Remove disk : No
AiCloud : No
Download master : No
AiDisk : No
Media Server : No
Time Machine : No
Samba Server : No
FTP Server : No
Shared Folder privileges : No
Administration
Operating system : ASUSWRT
Free OS upgrade : Yes
Firewall : Yes
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL) : Yes
SSH : Yes
Configuration backup and restore : Yes
Diagnosis tools : Yes
Feedback system : Yes
System log : Yes
Free OS upgrade : Yes
Firewall : Yes
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL) : Yes
SSH : Yes
Configuration backup and restore : Yes
Diagnosis tools : Yes
Feedback system : Yes
System log : Yes
Product Dimensions with antennas (L*W*H) mm
90 x 90 x 80 mm
Gift Box Dimension (L*W*H) mm
1PK : 235*155*130 mm
3PK : 369*199*131 mm
2PK : 260*195*127 mm
3PK : 369*199*131 mm
2PK : 260*195*127 mm
Gift Box Weight (kg)
1PK : 0.37
3PK : 0.5
2PK : 0.48
3PK : 0.5
2PK : 0.48
Carton Dimension (L*W*H) mm
1PK : 537*493*179 mm
3PK : 543*384*220 mm
2PK : 409*277*221 mm
3PK : 543*384*220 mm
2PK : 409*277*221 mm
Carton Gross Weight (kg)
1
