AMD CORES 16 THREADS 32 PROCESSOR RYZEN-THREADRIPPER-1950X CPU

FEATURES Overwhelming Power. The AMD Ryzen Threadripper processor is designed to provide indisputable multi-processing supremacy on the X399 ultimate platform for desktop. 16 cores provide an astonishing 32 threads of simultaneous multi-processing power, while 40MB of combined cache and vast I/O from the enthusiast-grade AMD X399 platform stand ready to feed the beast.

16 cores and 32 threads for lightning-fast creative workloads.
An unprecedented 64 PCIe® Gen3 lanes to meet large GPU and NVMe needs.

SKU:Ryzen TR 1950X

16 cores and 32 threads for lightning-fast creative workloads.
An unprecedented 64 PCIe® Gen3 lanes to meet large GPU and NVMe needs.
40MB of combined cache for rapid access to large data sets.
Quad channel DDR4 with support for ECC for reliable throughput.

The “Zen” Core Architecture Built with AMD SenseMI Technology to deliver a truly intelligent processor.

AMD SenseMI Technology Technology that thinks, featuring a true Neural Network.

AMD Ryzen Master Utility The Simple and Powerful Overclocking Utility for AMD Ryzen processor.

AMD Ryzen™ VR-Ready Premium For the best possible VR experiences, AMD offers select Ryzen™ VR-Ready Premium processors.

Virtualization Pure. Virtualized. Graphics.

SERIES

Ryzen Threadripper

CORES

16 Cores

SPEED

3.4 GHz

SPEED (TURBO)

4.0 GHz

CACHE

40 MB

DETAILED SPEC.

Specifications
Cores	16
Threads	32
Base Clock Speed	3.4GHz
Max Turbo Core Speed	4GHz
Total L1 Cache	1.125MB
Total L2 Cache	8MB
Total L3 Cache	32MB
Unlocked	Yes
CMOS	14nm
Package	sTR4
PCI Express Version	PCIe 3.0
Default TDP / TDP	180W
Max Temps	68°C
Memory
Max Memory Speed	2667MHz
Memory Interface	DDR4
Memory Channels	4
Key Features
Supported Technologies	The “Zen” Core Architecture AMD SenseMI Technology AMD Ryzen Master Utility AMD Ryzen™ VR-Ready Premium Virtualization AES AVX2 FMA3
Foundation
Product Family	AMD Ryzen Threadripper
Product Line	AMD Ryzen™ Threadripper 1950X
Platform	Desktop
